NY-D01 100A Digital Display Spot Welding Controller Board
Candle Safety
1. Trim your wick before burning your candle the first time and every subsequent burn thereafter.
2. We advise burning your candle for periods of no longer than three hours at a time.
3. Discontinue burning your candle when there is 10mm / 1cm of wax is remaining.
4. Always burn your candle on a stable and heat resistant surface, away from drafts or items that can catch alight.
5. Never leave a burning candle unattended, near children or pets.
6. If you’re burning more than one candle at a time, space your candles approximately 100mm (10cm) apart.
The principle of silicon-controlled phase shifting triggering is adopted to adjust the time and the current to achieve welding. With a digital display, you can directly see the time and current. Optocoupler isolates the strong and weak electricity, making the operation safer. Using a high-precision single potentiometer to ensure reliable and convenient input. The design of a reliable zero-crossing detection circuit ensures the SCR phase shift accuracy. Made of high-quality PCB, the control board is long-lasting. The module is 8cm long, 6cm wide, and 2cm high. It is developed for DIY or simple resistance welding. Features: 1 The use of STM8 industrial control center microcontroller. 2 Strong and weak electricity through optocoupler insulation, safe operation. 3 The power line and foot switch line adopts the bolt the quick connect terminal, more convenient and reliable. 4 Input time, current using a high-precision simple potentiometer, to ensure reliable, convenient input 5 On-board power supply, state, foot, trigger indicator, work status clearly visible. 6 The design of reliable zero-crossing detection circuit to ensure that the SCR phase shift accuracy. 7 The controller is compatible with 100A scr. 8 Digital control interface, you can display the current time and current settings. 9 Input time of 1-50, cycle unit (1 cycles is 20 ms), current input (30-99%). Material: Plastic Metal The controller is compatible with 100A scr. Digital control interface, you can display the current time and current settings. Time input 1-50, unit cycle (1 cycles is 20ms) DOWNLOAD MANUAL NY-D01-210623 DIY Spot Welder From Microwave – Now With OLED Display! _ 8 Steps (with Pictures) – Instructables
